HIBO converter for battery-free calling systems HIBO RECS USA

The device is designed to convert and amplify the signal of transmitting devices - HIBO call buttons operating in battery-free HIBO RECS personnel call systems.

Since the HIBO call buttons operate in a special pulse mode, this HIBO converter is required to correct their signals and convert them into a standard RECS signal. It also amplifies the signals. Thus, you get an inexpensive amplifier and a powerful coverage area in the RECS standard.

Note. The system uses only one HIBO converter. To increase the range of the system, you can additionally use RECS R-002 amplifiers.
Thus, one system can consist of any number of HIBO buttons without batteries, one HIBO converter and any number of amplifiers, receivers and pagers.

Installation of the HIBO personnel call signal converter

The location of the converter depends on many factors - the area of ​​the premises, the number of floors and architectural features of the building, and when working in open space, on the terrain. The RECS HIBO converter is permanently installed (on the wall or ceiling) within a radius of up to 20 meters from the call buttons and is connected to a 220 Volt power supply. The converter is easily and simply configured with HIBO buttons.

Poribor powerfully broadcasts call signals over a distance of up to 800 meters! If necessary (with a large service area), it may be necessary to install additionally any number of converters for independent operation and powerful signal amplification. To select the most optimal location, the converter should be placed at an equal distance from the buttons.

Technical characteristics of the HIBO RECS converter

- operating frequency: 433.92 MHz;
- operating voltage: DC12V;
- converter signal power 100 mW;
- transmission power: 500 mW;
- signal transmission range: 300 m indoors / 800 m outdoors
- power supply: 220 Volts via 12 V / 2 A adapter (included).

Delivery package of the HIBO RECS converter

The kit includes:

1. HIBO RECS converter.
2. Removable antennas.
3. Power supply.
4. Installation kit.
